| Inputs |
+ 12 active inputs, 42 total input plugs |
|
+ 6x HDMI (3x HDMI up to 4k30hz included) |
|
+ 3x DisplayPort (up to 4k30hz) |
|
+ 9x DVI-I (3x DVI Dual-Link up to 2560×1600 included) |
|
+ 12x 3G/HD/SD-SDI |
|
+ 12x Universal Analog (6x HD15 & 6x DVI-A) |
|
— |
| Outputs |
+ 4 outputs with 5 plugs per output |
|
+ 8x Universal Analog (4x HD15 & 4x DVI-A) |
|
+ 4x 3G/HD/SD-SDI |
|
+ 2x DVI-I Dual-Link up to 2560×1600 (output #1 and #3) |
|
+ 2x DVI/HDMI 4K up to 4k30hz 4:4:4 or up to 4k60hz |
|
+ 4:2:0 (output #2 and #4) |
|
+ 4x SFP (Optical for SDI Fiber transmission) |
|
— |
| Monitoring Outputs |
+ 2x Universal Analog (HD15 & DVI-A) |
|
+ 1x DVI-I |
|
+ 2x 3G/HD/SD-SDI |
|
+ 1x RGBs/RGsB/RGB/YPrBr/YC/comp analog output |
|
+ Customizable labels – Up to 12 widgets |
|
— |
| Layers |
+ 6 True-Seamless scaled layers or 3 True-Seamless |
|
+ Perspective Layers per output |
|
+ 1 native background layer per output |
|
+ Advance layer management |
|
— |
| Transitions Effects |
+ True A/B Mix |
|
+ Borders: Edge, Smooth, Smooth Edge, Shadow… |
|
+ Transitions: Cut, Fade, Slide, Wipe, Circle, Stretch, |
|
+ Depth, Flying window |
|
+ Layer effects: Background Cut, Transparency, |
|
+ Luma/Chroma Key, DSK, H&V Flip, Cut and Fill |
|
+ Colors effects: B&W, Negative, Sepia and Solarize |
|
— |
| Frames Logos |
+ Up to 100 frame/logo memories – Fully resizable |
|
+ Download/upload via Web RCS |
|
+ Capture from live inputs |
|
— |
| Control |
+ Web RCS: On-board intuitive web based user interface |
|
+ VertigeTM: Premium remote controller |
|
+ RCU: Rack mountable master control unit |
|
+ Shot Box2 |
|
+ /Control Box2 |
|
+ Cost effective control solutions |
|
+ TCP protocol and AMX/Crestron drivers |
|
+ AW VideoCompositor: Drag & drop Crestron® GUI |
